Rod mill is sometimes used in mineral processing, and its technical standard is not high, which can adapt to the sand making needs of a variety of materials. It is widely used in the construction sand processing and production.Therefore, the working characteristics of the two are obviously different, and the discharge particle size is more uniform. At present, there is no specification related to the rod mill sand making steel bar. Three of the more common ones include ball mill, rod grinding sand machine and autogenous mill.
There is no inertia impact, the equipment runs smoothly, and reduces the downtime and maintenance time of the mill, improving the efficiency.
Using high quality plate, lining can be replaced, rotary gear using casting gear hobbing processing, the cylinder body is inlaid with wear-resistant lining plate, has good wear resistance.
Ball mill and classifier form closed system, negative pressure conveying, small dust, green environment protection.
The bearing body is lubricated by grease, which greatly reduces friction resistance, and the fuel consumption is extremely low and the operation is more convenient.
| Model specification | Cylinder diameter(mm) | Cylinder length(mm) | Cylinder speed(r/min) | Rod loading weight(t) | Feed size(mm) | Discharge size(mm) | Output(t/h) | Motor power(Kw) | Weight(t) |
| KLF2436 | 2400 | 3600 | 19 | 28 | <25 | 0. 8-5.0 | 26-65 | 280 | 58 |
| KLF2736 | 2700 | 3600 | 17.5 | 42 | <25 | 0. 8-5.0 | 30-125 | 400 | 86 |
| KLF2740 | 2700 | 4000 | 17.5 | 47 | <25 | 0. 8-5.0 | 40-150 | 400 | 91 |
| KLF3040 | 3000 | 4000 | 16.2 | 51 | <25 | 0. 8-5.0 | 62-165 | 500 | 130 |
| KLF3245 | 3200 | 4500 | 15.5 | 56 | <25 | 0. 8-5.0 | 70-210 | 630 | 137 |
| KLF3248 | 3200 | 4800 | 15.5 | 60 | <25 | 0. 8-5.0 | 75-240 | 710 | 142 |
| KLF3645 | 3600 | 4500 | 14.5 | 78 | <25 | 0. 8-5.0 | 83-260 | 1000 | 168 |
| KLF3654 | 3600 | 5400 | 14.5 | 94 | <25 | 0. 8-5.0 | 100-330 | 1120 | 192 |
